OVİS Anakart

OVMB-ARM-A33

64Bit processor. Dual-core Cortex-A72 up to 1.8GHz Quad-core Cortex-A53 up to 1.4GHz

Various display interfaces: Dual-LVDS, EDP, HDMI etc.

Various expansion interfaces: OVMB-ARM-A33 has seven USB ports(A TYPEC and four internal
expansion ports, two USB standard ports.), a 485 port, four expansion serial ports(TTL*2, one has
hard flow control, RS232*2), GPIO port and ADC port, OVMB-ARM-A33 can satisfy your customization
requirement.

Various internet:100M,1000M Ethernet, 5G/2.4G WIIF supported, Independent dual-antenna,
built-in PCI-E 3G/4G module.

High def inition.OVMB-ARM-A33 supports 4K 3840×2160 decoding, it also supports Special-shaped
screen with LVDS/EDP/HDMI interfaces and it has multi-monitor extend display mode.

Android system customization. OVMB-ARM-A33 provides system calling interface and API reference
code, it supports upper-layer applications development perfectly.

OVMB-ARM-A33 supports infrared, optical, capacitance, resistance and other mainstream touch screen,
it also supports drive-free HID configuration which no need to debug before using

OVİS Anakart

OVMB-ARM-A33

OVMB-ARM-A33 uses RK3399,a 64bit supper processor with dual-core Cortex-A72 and quad-core
Cortex-A53,its basic frequency is 1.8GHz, OVMB-ARM-A33 Uses Mali-T860 GPU, it has H.265 hardware
decoder to supports 4K display. OVMB-ARM-A33 integrated Dual-LVDS, EDP, HDMI display output interfaces
to itself, with common backlight panel interface and screen level jumper, JWS3399 is compatible to
various types of display screen.With powerful performance and fast process speed, OVMB-ARM-A33 is your
best choice for human-computer interaction, intelligent terminal and industrial control projects
